WB-AS-9108ULG-W
Model: | WB-AS-9108ULG-W |
Place of Origin: | Zhejiang,China (Mainland) |
Dimensions: | 630*450*42mm |
Advised Rack depth: | 900mm ~ 1200mm |
LCD MTBF: | 50,000 hours |
Input Power: | DC 12V |
Resolution(max): | 1920*1080 60HZ |
visible square: | 409.8(H)*230.4(V)mm |
Certificate: | CE,ISO,ROHS |
Product Description
Payment & Shipping Terms | Supply Capacity | ||
Unit Price: | 1.0 USD | Production Capacity: | 5000 pcs per month |
Trade Term: | FOB,CFR,CIF,DDP,EXW | Packing: | Cartons |
Payment Terms: | L/C, WU, T/T, Paypal | Delivery Date: | Within 30 days |
MOQ: | 2 Piece/Pieces | ||
Means of Transport: | Land, Ocean, Air |
Wide screen type 19 8 port VGA LCD KVM
Control platform with LCD, keyboard, mouse and 8port KVM switch.
1U height, suitable for 18.51'' standard cabinet installation and metal structure.
18.51" LED widescreen with high brightness, high clear and high resolution.
Control platform can be totally pulled out from the cabinet and the LCD screen can be turned on to 120 degrees.
Ultra thin keyboard with keypad.
Mouse touch board with two function button.
Front panel with lock to prevent damage by accident.
Built-in power.
Automatic power on/off.
When pulling control platform out from cabinet, the power turns off automatically. When pushing it into the cabinet, the power turns on automatically.
An easy-to-use OSD menu.
Switch
One control platform can control 8pcs computers by direct connection
Be compatible with PS/2, USB standard interface.
Support VGA, SVGA, XGA video input.
Accord with DDC, DDC2, DDC2B standard and VESA standard.
Support maximum resolution of 1920 * 1080
Support multiple operating systems: WIN95/98/98SE/ME/200/XP,WIN 7,WIN NT,UNIX,LINUX.
Package
Model NO. | Description |
WB-AS-7104ULG | 17" screen , 4 VGA port |
WB-AS-7108ULG | 17" screen , 8 VGA port |
WB-AS-7116ULG | 17" screen , 16 VGA port |
WB-AS-9104ULG | 19" screen , 4 VGA port |
WB-AS-9108ULG | 19" screen , 8 VGA port |
WB-AS-9116ULG | 19" screen , 16 VGA port |
WB-AS-7104TLG | 17" screen , 4 Cat5e port |
WB-AS-7108TLG | 17" screen , 8 Cat5e port |
WB-AS-7116TLG | 17" screen , 16 Cat5e port |
WB-AS-9104TLG | 19" screen , 4 Cat5e port |
WB-AS-9108TLG | 19" screen , 8 Cat5e port |
WB-AS-9116TLG | 19" screen , 16 Cat5e port |
-D | Option: Dual rail operaiton |
-W | Option: Wide screen |
