WB-AI7116TLG

Model:

WB-AI7116TLG

Place of Origin:

Zhejiang,China (Mainland)

Export Area:

all over the world

CPU port selection:

Front panel switches/OSD menu

IP Port:

Cat5

Power:

DC12V, 4A

Video resolution:

1280 x 1024

Dimensions:

446 x 636 x 44 mm


Product Description

Payment & Shipping Terms

Supply Capacity

Unit Price:

1.0 USD

Production Capacity:

3000 units per month

Trade Term:

FOB,CFR,CIF,DDP,EXW

Packing:

Cartons

Payment Terms:

L/C, WU, T/T, Paypal

Delivery Date:

Within 30 days

MOQ:

2 Piece/Pieces



Means of Transport:

Land, Ocean, Air





Remote control 16 cat5 ports LCD KVM Switch


Features:

Control platform with LCD, keyboard, mouse and multiple ports CAT5 KVM switch.

1U height, suitable for 19-inch standard cabinet installation and metal structure, 17" LCD screen with high brightness, high clear and resolution

Control platform can be totally pulled out from the cabinet and the LCD screen can be turned on to 120°

Ultra thin keyboard with keypad, mouse touch board with two function button.

Front panel with lock to prevent damage by accident, built-in power, automatic power on/off.

when pulling control platform out from cabinet, the power turns off automatically.

when pushing it into the cabinet, the power turns on automatically.

An easy-to-use OSD menu.


Switch:

One control platform can control 16 computers by direct connection, compatible with USB standard interface.

Supports VGA, SVGA, XGA video input, accord with DDC, DDC2, DDC2B standard and VESA standard, supports maximum resolution of 1920 x 1440

Supports multiple operating systems: Windows 95/98/98SE/ME/200/XP, 7, Vista, NT, UNIX, Linux

IP module: to realize the remote control by IP card



Type

WB-AI7116TLG

Computer connections

16

CPU port selection

Front panel switches/OSD menu

Console connectors

Keyboard

Disassembled standard 99-key keyboard


Mouse

Disassembled standard PS/2 touch pad


Video

17 inch SXGA color TFT-LED

Dongle connectors

Keyboard

1 x PS/2 male (purple)

1 x USB male


Mouse

1 x PS/2 male (green)



Video

16 x HDB-15 male (blue)

IP Port

Network

RJ45 port

LEDs

On Line

16 red LEDs


Selected

16 green LEDs

Video resolution(optimal)

1280 x 1024

Power

DC12V, 4A

Power adaptor

External: DC 12V

Operating temperature

-10˚C~50˚C

Storage temperature

-20˚C~60˚C

Housing

Metal

Weight

18.6 Kg

Dimensions(L x W x H )

446 x 636 x 44 mm


Photo show


IP module [can be swappable]




Package


Order information

Model NO.

Description

WB-AI-7104ULG

17" screen , 4 VGA port, Remote control

WB-AI-7108ULG

17" screen , 8 VGA port, Remote control

WB-AI-7116ULG

17" screen , 16 VGA port, Remote control

WB-AI-9104ULG

19" screen , 4 VGA port, Remote control

WB-AI-9108ULG

19" screen , 8 VGA port, Remote control

WB-AI-9116ULG

19" screen , 16 VGA port, Remote control

WB-AI-7104TLG

17" screen , 4 Cat5e port, Remote control

WB-AI-7108TLG

17" screen , 8 Cat5e port, Remote control

WB-AI-7116TLG

17" screen , 16 Cat5e port, Remote control

WB-AI-9104TLG

19" screen , 4 Cat5e port, Remote control

WB-AI-9108TLG

19" screen , 8 Cat5e port, Remote control

WB-AI-9116TLG

19" screen , 16 Cat5e port, Remote control

 -D

Option: Dual rail operaiton, Remote control

 -W

Option: Wide screen
