WB-CS21UA

Model:

WB-CS21UA

Place of Origin:

Zhejiang,China (Mainland)

Size:

86 x 86 x 26.5 mm

USB Port:

2

Housing:

plastic

Female VGA:

3

audio port:

2

Resolution:

1920 x 1440


Product Description

Payment & Shipping Terms

Supply Capacity

Trade Term:

FOB,CFR,CIF,DDP,FCA,EXW

Production Capacity:

10000 pcs/month

Payment Terms:

L/C, WU, T/T, Paypal

Packing:

cargo

MOQ:

1 Piece/Pieces

Delivery Date:

25 days

Means of Transport:

Land, Ocean, Air




2-port USB series desktop KVM switch

Function

2 ports Webitelecomms KVM switch, controlling 2 servers or 2 PC via a   single console (USB).

Allows users to switch between computers via   buttons on the front panel of the switch or hot key configuration on the keyboard.

It is the simplest and most convenient solution for multi-computers management.

Stablecapability&sturdy, durable and small design are the most important features for this series products.



Key Specifications/Special Features:

Easy to install

Supports hot key switching and hot plugging

Software installation is not required

LED indicates working status

Supports Windows 98/NT/Me/XP/Vista/7, Linux, Unix, Netware,OS/2 and all application programs



One usb keyboard, usb mouse, monitor controls Four PCs

1) Bandwidth: 570MHZ
2) No software, No driver required.
3) Switch mode: Hot key on the keyboard (version A---"CTRL + CTRL")

(version B---"SCROLL+SCROLL+Up/Down arrow" or "SCROLL+SCROLL+1,2")

4) With audio switch

5) No external power required

6) LED indicate the current state

7) Cable length: 90cm or other lengths



Type

WB-CS-21UA

Computer connections

2

CPU port selection

Front panel switches/Hot key

Console connector

Keyboard

1 x USB female

Mouse

1 x USB female

Monitor

1 x HDB-15 female

CPU connection

Keyboard

2 x 6pin mini-DIN female(PS.2)

Mouse

2x 6pin mini-DIN female(PS.2)

Monitor

2x HD15 male

LEDs

Online (red)

2

Selected (orange)

2

Video resolution

1920 x 1440

Power

DC5V, 400mA (for optional)

Operating temperature

-10˚C~50˚C

Storage temperature

-20˚C~60˚C

Housing

Plastic

Weight

0.61 kg

Dimensions(L x W x H )

86 x 86 x 26.5 mm



A side



B side



C side



D side



Overview



 FAQ



1)    What is your Payment term?

---TT, LC, Western Union could be accepted.



2)    What is your Trade term?

---EXW, FOB, CNF, CIF,DDP , We're flexiable since the trade term is reasonable .



3)    What is the Loading Port?

--- Ningbo or Shanghai.



4)    What is your MOQ?

---MOQ of most our products is 5pcs, different items will be different. We have indicated the MOQ for each item

in the price list.



5)    What kind of certfications can ensure your quality problem?

---As Europe market, we have CE RoHS and other international safety standard for our products.

---As other market,international safety standard certificate also could be provided.



6)  How long I can get your price ?

--- 24*7 service is ready, 30 mins - 38 hours , you will get the price!





Order information



Model NO.

Description                                                                                     .

WB-CS-21UA

Plastic case desktop series KVM , 2 VGA port

WB-CS-41UA

Plastic case desktop series KVM , 4 VGA port

WB-CS-21CA

Plastic case desktop series KVM , 2 Cat5e port

WB-CS-41CA

Plastic case desktop series KVM , 4 Cat5e port

WB-AS-21P

Metal case desktop series KVM, 2 PS/2 port , 2 VGA port

WB-AS-21UA

Metal case desktop series KVM, 2 USB port with audio  , 2 VGA port

WB-AS-41P

Metal case desktop series KVM, 4 PS/2 port , 4 VGA port

WB-AS-41UA

Metal case desktop series KVM, 4 USB port with audio  , 4 VGA port

WB-LS-21CS

Plastic case 2 ports cable KVM,support PS/2

WB-LS-21CA

Plastic case 2 ports cable KVM,support PS/2 with audio

WB-LS-21JS

Plastic case 2 ports cable KVM, support USB

WB-LS-21JA

Plastic case 2 ports cable KVM,support USB with audio

WB-LS-41JA

Plastic case 4 ports cable KVM,support USB with audio

WB-LS-41CU

Plastic case 4 ports cable KVM (combo), support USB&PS.2 with audio
