WB-AS21P
Model: | WB-AS21P |
Place of Origin: | Zhejiang,China (Mainland) |
Size: | 132*92*42mm |
Housing: | metal |
PS/2: | 2 |
Female VGA: | 1 |
Male VGA: | 2 |
Product Description
Payment & Shipping Terms | Supply Capacity | ||
Trade Term: | FOB,CFR,CIF,DDP,FCA,EXW | Production Capacity: | 10000 pcs/month |
Payment Terms: | L/C, WU, T/T, Paypal | Packing: | cargo |
MOQ: | 1 Piece/Pieces | Delivery Date: | 25 days |
Means of Transport: | Land, Ocean, Air |
Metal Case Desk-top KVM SWTICH
Specifications
Aim to use one usb keyboard, usb mouse, monitor controls two PCs
1) Support DOS, WIN3.X,WIN95/98/98SE/2K/ME/XP/NT,Apple, MAC Linux, Netware,Unix, Etc
2) Bandwidth: 570MHZ
3) No software, No driver required.
4) Switch mode: Hot key on the keyboard (version A---"CTRL + CTRL")
(version B---"SCROLL+SCROLL+Up/Down arrow" or "SCROLL+SCROLL+1,2")
5) With audio switch
6) No external power required
7) LED indicate the current state
8) Cable length: 90cm or other lengths
9) 2 PCs port, 1 console port, 2 max. PC connections.
10) PC port connector: PS/2 keyboard mini din 6pins VGA HDDB 15pins.
11) Console port connector: PS/2 keyboard mini din 6pins PS/2 mouse mini din 6pins
12) PC selection: button
13) Keyboard emulation: PS2
14) Mouse emulation(Console port to PC port): PS2
15) VGA resolution: 1920X1440
17) Housing: Metal
SAMPLE photos
Order information
Model NO. | Description |
WB-CS-21UA | Plastic case desktop series KVM , 2 VGA port |
WB-CS-41UA | Plastic case desktop series KVM , 4 VGA port |
WB-CS-21CA | Plastic case desktop series KVM , 2 Cat5e port |
WB-CS-41CA | Plastic case desktop series KVM , 4 Cat5e port |
WB-AS-21P | Metal case desktop series KVM, 2 PS/2 port , 2 VGA port |
WB-AS-21UA | Metal case desktop series KVM, 2 USB port with audio , 2 VGA port |
WB-AS-41P | Metal case desktop series KVM, 4 PS/2 port , 4 VGA port |
WB-AS-41UA | Metal case desktop series KVM, 4 USB port with audio , 4 VGA port |
WB-LS-21CS | Plastic case 2 ports cable KVM,support PS/2 |
WB-LS-21CA | Plastic case 2 ports cable KVM,support PS/2 with audio |
WB-LS-21JS | Plastic case 2 ports cable KVM, support USB |
WB-LS-21JA | Plastic case 2 ports cable KVM,support USB with audio |
WB-LS-41JA | Plastic case 4 ports cable KVM,support USB with audio |
WB-LS-41CU | Plastic case 4 ports cable KVM (combo), support USB&PS.2 with audio |
