WB-OR-Bxxxx
-
WB-OR-Cxxxx
WB-OR-A1xxxx
| Model: | WB-OR-A1 |
| Place of Origin: | Zhejiang,China (Mainland) |
| Brand Name: | Webitelecomms |
| Certificate: | CE,ISO, ROHS,SGS |
| Material: | SPCC cold rolled steel or EG steel |
| Thickness: | 1.5~2.0 mm |
| Plinth: | 350 mm depth |
Contact NowProduct Description
| Payment & Shipping Terms | Supply Capacity | ||
|---|---|---|---|
| Payment Terms: | L/C, WU, T/T | Production Capacity: | 10000 units per month |
| MOQ: | 50 Piece/Pieces | Packing: | Ctns, Wooden cases |
| Means of Transport: | Land, Ocean, Air | Delivery Date: | 10-20days |
2 post open rack
Features:
Open rack with 2 posts.
Easily assemble and disassemble for delivery, low-cost.
Can be bolted directly to floor
Maximum access for cable management and equipment maintenance
Various optional accessories according to requirements (cable management slot, removable working panel, etc).
Flexible packing methods allows for convenient stocking and end user delivery.
Multiple sizes available.
Customization requests welcome
Standard and Material:
Comply with ANSI/EIA RS-310-D,IEC297-2,DIN41491;PART1,DIN41494;PART7, ETSI standard.
Main materials:SPCC cold rolled steel or EG steel
Thickness: Plinth:2.0mm; Front and bottom beams 2.0mm, pole:1.5mm.
Surface Finish:Degreasing, pickling, phosphoric, powder coated.
Loading capacity:150KG Static loading,from 12U to 47U capacity
Body color:RAL9004(black);RAL7035(grey),etc
-Accessories matching-:
PDU | - eg. 6-way country-spec series PDU |
Patch panels | - eg. 24-port Cat6 UTP patch panel |
Shelves | -eg. 2-point cantilever shelf |
Cable managers | -eg. 5-ring cable management |
Brush panel | -eg. 1U brush panel for wiring |
Others | etc.. |
=Shipment & Delivery =
Shipment | Note |
Express | Door to door, very convenient, don't need to clearance or pick-up |
By air | Airport to airport, you need to do the customs clearance and pick up the goods at your local airport |
By sea | Port to port and you need to do the customs clearance and pick-up the goods at your local port |
Webitelecomms take great commitments to photograph products indeed without any cheating and plagiarism.
Size list
| Part NO. | Width | Depth | U | H(mm) |
| WB-OR-A1-6318 | 600 | 350 | 18 | 923 |
| WB-OR-A1-6322 | 22 | 1101 | ||
| WB-OR-A1-6327 | 27 | 1323 | ||
| WB-OR-A1-6332 | 32 | 1545 | ||
| WB-OR-A1-6337 | 37 | 1768 | ||
| WB-OR-A1-6342 | 42 | 1990 | ||
| WB-OR-A1-6345 | 45 | 2123 | ||
| WB-OR-A1-6347 | 47 | 2212 |
