| Model: | WB-CA-47 |
| Place of Origin: | Zhejiang,China (Mainland) |
| Brand Name: | Webitelecomms |
| Certificate: | CE,ISO, ROHS,SGS,REACH |
| Materials: | SPCC steel |
| Thickness: | Customized |
| Color: | Black/Grey |
| Logo: | optional embossment |
| Treatment: | Powder coated |
| Surface: | Matte or frosting |
Contact NowProduct Description
| Payment & Shipping Terms | Supply Capacity | ||
|---|---|---|---|
| Trade Term: | FOB,CFR,CIF,DDP,DAP,FCA,EXW | Production Capacity: | 50000 units per week |
| Payment Terms: | L/C, WU, T/T, Paypal | Packing: | Ctns, Wooden cases |
| MOQ: | 1000 Piece/Pieces | Delivery Date: | 15days |
| Means of Transport: | Land, Ocean, Air | ||
4u 19" WALL MOUNT BRACKET used data cable Management with fold rails
Descriptions
1) Webitelecomms wall mount bracket offers variant depths bracket - designed with folable rails for convenient operating, which is used for structured cabling applications , as well as to save shipping and storage cost.
2) No complicated assmebling step required , easy and quick mountable when out of the box.
It mounts on standard 19" racks or cabinets and provided a clean, beautiful and simple means of organizing from small to large bundles of cables and patch cord
Feature
19" rack horizontal mountable,1U,2U, 4U, 6U variants for options
Powder coated metal body , adjustable depth
Up to 55lbs loading
Tapped with ANSI/EIA standard , US series is also available
Standard and Material: Comply with ANSI/EIA; RS-310-D; IEC297-2; DIN41491:PART1; DIN41494: PART7; GB/T3047.2-92 standard; compatible with ETSI standard.
Thickness:1.2mm / 1.5 mm / 2.0 mm
Surface finish: Degrease, acid pickling, rust prevention and parkerizing, pure water cleaning, static elecricity plastic painting.
Color: RAL9004 (black);RAL7035 (grey)
Package
1 pc / unit |
1 unit / box |
36 boxes/pallet |
Carton Size: 52 X 10 X 20 cm |
G.W.:3.5 kg/carton |
=Shipment & Delivery =
Shipment | Note |
Express | Door to door, very convenient, don't need to clearance or pick-up |
By air | Airport to airport, you need to do the customs clearance and pick up the goods at your local airport |
By sea | Port to port and you need to do the customs clearance and pick-up the goods at your local port |
Webitelecomms take great commitments to photograph products indeed without any cheating and plagiarism.
FAQ
1) What is your Payment term?
---T/T, L/C, Western Union could be accepted.
2) What is your Trade term?
---EXW, FOB, CNF, CIF all are available.
3) What is the Loading Port?
--- Ningbo or Shanghai port.
4) What is your MOQ?
---MOQ of most
webitelecomms products is usually
5pcs, different items will be different. the MOQ will be indicated
in the price list.
5) What is your Product Warranty?
---As Europe market, we have CE RoHS and other international safety standard for our products.
---As other market, international safety standard certificate is also be provided.
