WB-CA-45P
| Model: | WB-CA-45P |
| Place of Origin: | Zhejiang,China (Mainland) |
| Brand Name: | Webitelecomms |
| Certificate: | CE,ISO, ROHS,SGS,REACH |
| Materials: | Carbon steel , Plastic |
| Thickness: | Customized |
| Color: | Black/Blue/Red/Yellow |
| Logo: | optional embossment |
| Treatment: | Powder coated |
| Surface: | Matte or frosting |
Contact NowProduct Description
| Payment & Shipping Terms | Supply Capacity | ||
|---|---|---|---|
| Trade Term: | FOB,CFR,CIF,DDP,DAP,FCA,EXW | Production Capacity: | 50000 units per week |
| Payment Terms: | L/C, WU, T/T, Paypal | Packing: | Ctns, Wooden cases |
| MOQ: | 1000 Piece/Pieces | Delivery Date: | 15days |
| Means of Transport: | Land, Ocean, Air | ||
Data center rack cable tray used cable fixer , adjustable height
WB-CA-45P
is intended to used for INFRASTRUCTURE CABLING SYSTEM server rack, fill the cable tray with easy management
expecting.
Ensure a clean, beautiful and simple means of organizing from small to large bundles of cables internal ensure a clean, beautiful and simple means of organizing from small to large bundles of cables
Application
keep the cables organizing fixed
keep cabling easy management and maintance.
keep cabling from over-hot
keep data center well-look
Package
Webitelecomms neutral carton box packed
Plywood pallet for options
Size options
| Model | Size | Wire diameter fitness | Effective width |
| 65 | 65x40x4 mm | Φ 5~17 mm | 35 mm |
| 80 | 80x40x4 mm | Φ 5~25 mm | 50 mm |
| 88 | 88x40x4 mm | Φ 5~29 mm | 58 mm |
| 95 | 95x40x4 mm | Φ 5~32 mm | 65 mm |
| 115 | 115x40x4 mm | Φ 5~32 mm | 85 mm |
| 124 | 124x40x4 mm | Φ 5~32 mm | 94 mm |
| 135 | 135x40x4 mm | Φ 5~32 mm | 105 mm |
| 160 | 160x40x4 mm | Φ 5~42 mm | 130 mm |
| 196 | 196x40x4 mm | Φ 5~52 mm | 166 mm |
Basic information
| Model | WB-CA-45P |
| Cable Diameter | Φ 5mm to 17mm |
| Φ 5mm to 32mm | |
| Φ 5mm to 42mm | |
| Φ 5mm to 52mm | |
| Washer height | 5mm/6mm/8mm/10mm/12mm/14mm/15mm/16mm/17mm/18mm/20mm/23mm/25mm/30mm |
| Materials options | Carbon steel |
| flame retardant plastic | |
| Aluminum alloy | |
| Application | Cable tray management |
| Webit package | 5 layer export carton |
| Optional plywood pallet |
Body color : Black / Red / Yellow / Blue / Customized
# Sample galary
=Shipment & Delivery =
Shipment | Note |
Express | Door to door, very convenient, don't need to clearance or pick-up |
By air | Airport to airport, you need to do the customs clearance and pick up the goods at your local airport |
By sea | Port to port and you need to do the customs clearance and pick-up the goods at your local port |
Webitelecomms take great commitments to photograph products indeed without any cheating and plagiarism.
FAQ
1) What is your Payment term?
---T/T, L/C, Western Union could be accepted.
2) What is your Trade term?
---EXW, FOB, CNF, CIF is also ok.
3) What is the Loading Port?
--- Ningbo or Shanghai port.
4) What is your MOQ?
---MOQ of most our products is 5pcs, different items will be different. We have indicated the MOQ for each item in the price list.
5) What is your Product Warranty?
---As Europe market, we have CE RoHS and other international safety standard for our products.
---As other market, international safety standard certificate is also be provided.
