| Model: | WB-CA-01 |
| Place of Origin: | Zhejiang,China (Mainland) |
| Brand Name: | Webitelecomms |
| Certificate: | CE,ISO, RoHS,REACH |
| Materials: | SPCC+PA |
| Color: | Black or Grey |
| Surface: | Smooth as default / optional frosting |
| Height: | 1U / 2U / 3U ,etc |
| Silk print: | OEM brand / Neutral |
| Package: | PVC bag + brown box |
Contact NowProduct Description
| Payment & Shipping Terms | Supply Capacity | ||
|---|---|---|---|
| Unit Price: | 1.0 USD | Production Capacity: | 10000 units per month |
| Trade Term: | FOB,CFR,CIF,DDP,FCA,EXW | Packing: | standard cargo packing |
| Payment Terms: | L/C, WU, T/T, Paypal | Delivery Date: | 20 days |
| MOQ: | 50 Piece/Pieces | ||
| Means of Transport: | Land, Ocean, Air | ||
19" 1U brush panel for cabling system
Features:
Suitable for 19" standard cabinet
with PA brush material
with 1u or 2u height
Body material can be metal or PC
Dust-proof and cable-protection
SPCC cold rolled steel
1.2mm thickness for Body, smell-less brush with RoHS comply
Dimensions:483*45*8mm
Standard:
1.Comply with ANSI/EIA;RS-310-D;IEC297-2;DIN41491:PART1;DIN41494:PART7; GB/T3047.2-92 standard; compatible with ETSI standards.
2.Surface Finish: Degreasing, pickling, phosphoric, power coating.
3.Material: SPCC cold rolled steel with PA brush;
4.Color: RAL9005(black).
5.Installation:International standard 19 inch used on network cabinets.
6.thickness:1.20 mm .
Sample show
-5N brush
-Screw type & defaulted type
1. Screw series frame
2. defaulted series frame
2U sample
Package
Model no.: | Description: | Package: | Dimension | Weight |
WB-CA-01 | Brush panel | Neutral package 50pcs/Ctn | 51X31X42 cm | 15kgs |
pallet package (optional)
=Shipment & Delivery =
Shipment | Note |
Express | Door to door, very convenient, don't need to clearance or pick-up |
By air | Airport to airport, you need to do the customs clearance and pick up the goods at your local airport |
By sea | Port to port and you need to do the customs clearance and pick-up the goods at your local port |
Webitelecomms take great commitments to photograph products indeed without any cheating and plagiarism.
FAQ
1) What is your Payment term?
---T/T, L/C, Western Union could be accepted.
2) What is your Trade term?
---EXW, FOB, CNF, CIF are all available.
3) What is the Loading Port?
--- Ningbo or Shanghai port.
4) What is your MOQ?
---
Webitelecomms cable management sold with mini quantity order #
100pcs, different items will be different. We have indicated the MOQ for each item in the price list.
5) What is your Product Warranty?
---As Europe market, we have CE RoHS and other international safety standard for our products.
---As other market, international safety standard certificate is also be provided
