WB-AI9108
Model: | WB-AI9108 |
Place of Origin: | Zhejiang,China (Mainland) |
Power: | DC9V 1000mA |
Video resolution: | 1600 x 900 |
Dimensions: | 432 x 155 x 44 mm |
Port: | 8 VGA port |
peripheral connector: | PS2 / USB free combo |
Housing: | Metal |
Product Description
Payment & Shipping Terms | Supply Capacity | ||
Unit Price: | 1.0 USD | Production Capacity: | 3000 units per month |
Trade Term: | FOB,CFR,CIF,DDP,FCA,EXW | Packing: | Cartons |
Payment Terms: | L/C, WU, T/T, Paypal | Delivery Date: | Within 30 days |
MOQ: | 2 Piece/Pieces | ||
Means of Transport: | Land, Ocean, Air |
16 ports Rack-mounted VGA KVM Switch
Supports USB/PS/2 with OSD menu, which controls 8 PC/16 servers
One full set of monitor, keyboard, mouse-rack mountable, PC connection ports supports PS/2 and USB
Console port: supports USB and PS/2
Type | WB-AI9108 | |
Computer connections | 8 | |
CPU port selection | Front panel switches/OSD menu | |
Console connectors | Keyboard | 1 x PS/2 female (purple), 1 x USB Female |
Mouse | 1 x PS/2 female (green), 1 x USB Female | |
Cascade In | 1 x HD-15 female (blue) | |
Cascade Out | 1 x HD-15 female (blue) | |
Video | 1 x HD-15 female (blue) | |
CPU connectors | Keyboard | 1 x PS/2 female (purple), 1 x USB female |
Mouse | 1 x PS/2 female (green), 1 x USB female | |
Video | 8 x HDB-15 male (blue) | |
IP Part | Net connect | 1 x RJ45 |
Fettle | LED green | |
Reset | 1 x Switch | |
LEDs | On Line | 8 |
Selected | 8 | |
Video resolution | 1600 x 900 | |
Power | DC9V 1000mA | |
Operating temperature | -10˚C~50˚C | |
Storage temperature | -20˚C~60˚C | |
Housing | Metal | |
Weight | 0.8 Kg | |
Dimensions(L x W x H ) | 432 x 155 x 44 mm |
Order information
Model NO. | Description |
WB-KS-3104 | Rack mountable KVM switch, 4 Cat5e port |
WB-KS-3108 | Rack mountable KVM switch, 8 Cat5e port |
WB-KS-3116 | Rack mountable KVM switch, 16 Cat5e port |
WB-KI-3104 | Rack mountable KVM switch, 4 Cat5e port with remote control |
WB-KI-3108 | Rack mountable KVM switch, 8 Cat5e port with remote control |
WB-KI-3116 | Rack mountable KVM switch, 16 Cat5e port with remote control |
WB-AS-9104 | Rack mountable KVM switch, 4 VGA port |
WB-AS-9108 | Rack mountable KVM switch, 8 VGA port |
WB-AS-9116 | Rack mountable KVM switch, 16 VGA port |
WB-AI-9104 | Rack mountable KVM switch, 4 VGA port with remote control |
WB-AI-9108 | Rack mountable KVM switch, 8 VGA port with remote control |
WB-AI-9116 | Rack mountable KVM switch, 16 VGA port with remote control |
